• Measure range: Temperature: -20.0 °C to 70.0 °C.
Accuracy:
- ± 0.5 °C @ 25 °C;
- ± 1 °C max. along the entire measured range.
• Measurement resolutions: Temperature: 0.1 °C.
• Memory capacity: 32.000 (32 k) logs.
• Measurement interval:
- 5 seconds min.
- 18 hours max.
• Power Supply: 3.0 V lithium battery (CR2032), built-in.
• Estimated battery autonomy:
- More than 400 days – Sampling rate of 1 minute;
- More than 500 days – Sampling rate of 30 minutes.
• Operating temperature: From -20 °C to 70 °C.
• Housing: Polyamide.
• Protection: Up to IP67.
• Dimensions: 78 x 23 x 10 mm.
• Equipment -PC data transfer time:
- Proportional to the number of records;
- 20 seconds to 32.000 records.
• PC Interface: Connector USB.
• LogChart ll software operation environment:
- Configurator software for Windows 8, 7 and XP;
- Menus in Portuguese, English or Spanish;
- Sets up, reads and displays data on the screen.
